Van De Graaff Generator

Van De Graaff Generator

SKU: SKU:39340

A Pitsco Exclusive

Spark a passion for experimenting with static electricity with this fun generator. Pitsco’s version of the classic generator uses a hand crank to move the belt, creating a charge that is transferred to the terminal and the silver dome on top. You can attach a string with tape and watch the ends rise from the ball or watch the ball throw off paper rings or circles or experiment in many other ways with it!

Requires assembly with a Phillips screwdriver, small wrench or pliers, and scissors. Assembled generator stands 10" tall.

Spark a passion for experimenting with static electricity with this fun generator. Pitsco’s version of the classic generator uses a...

Grades 9-12
Regular price $96.00 USD
Regular price $0.00 USD Sale price $96.00 USD
Shipping calculated at checkout.

In stock

Add To Wishlist

Specifications

  • Tools Required: Phillips screwdriver, small wrench or pliers, and scissors
  • Height: 10"

Safety

California Proposition 65 Warning: This product contains one or more chemicals known to the State of California to cause cancer, birth defects, and other reproductive harm.

SDS Sheets
View full details
Grades 9-12

What You'll Get

Van De Graaff Generator
  • 9 laser-cut parts
  • 2 large rubber bands
  • 4 screws (4-40 x 1/2")
  • 4 small hex nuts
  • 2 large hex nuts
  • 12 screws (6-32 x 3/8")
  • 2 screws (6-32 x 3/4")
  • 2 screws (6-32 x 1")
  • 4 stand-off posts (1")
  • 4 kep nuts
  • 2 acorn nuts
  • Nylock nut
  • Nylon spacer (5/8")
  • Nylon flat washer (#4)
  • Nylon flat washer (#6)
  • 6 bushings
  • White roller
  • Gray roller
  • Metal dowel pin (1-3/4")
  • Pinion gear (10-tooth)
  • Gear (60-tooth)
  • 2 leads with alligator clips
  • 2 wires with ring terminals
  • Aluminum foil tape
  • 4 self-adhesive rubber feet
  • Steel globe

Support Materials

  • Van de Graaff Generator - Troubleshooting and Maintenance
  • Van de Graaff Generator - Deburring the Gears
  • Van de Graaff Generator - Crank Handle Tips
Van de Graaff Generator - Troubleshooting and Maintenance
Van de Graaff Generator - Deburring the Gears
Van de Graaff Generator - Crank Handle Tips

Learning Values

Science icon

Science

  • Electrical charges
  • Electricity production
  • Friction
  • Mechanical energy
Technology icon

Technology

  • Data collection
  • Problem-solving
  • Safety
Engineering icon

Engineering

  • Data analysis
  • Electricity/electronics
  • Specifications
Math icon

Math

  • Logic
  • Measurements
  • Prediction
